参考号:42431-02200
Rear Axle
Height : 30.3 mm
Diameter : 259 mm
Centering Diameter : 55 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 9 mm
Minimum Thickness : 7.5 mm
Num. of holes : 5
Solid or Vented : S -
参考号:43512-42050
Front Axle
Height : 49.3 mm
Diameter : 296 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 25 mm
Num. of holes : 5
Solid or Vented : V -
参考号:43512-42040
Front Axle
Height : 46.5 mm
Diameter : 275 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 25 mm
Minimum Thickness : 22 mm
Num. of holes : 5
Solid or Vented : V -
参考号:5290733AB
Front Axle
Height : 52.8 mm
Diameter : 359.8 mm
Centering Diameter : 72.1 mm
Pitch Circle Diameter : 127 mm
Brake Disc Thickness : 32 mm
Minimum Thickness : 31.8 mm
Num. of holes : 5
Solid or Vented : V
Weight : 13 kg -
Front Axle, Left
Height : 60 mm
Diameter : 357 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 34 mm
Minimum Thickness : 31 mm
Num. of holes : 5
Solid or Vented : V -
Front Axle, Right
Height : 60 mm
Diameter : 357 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 34 mm
Minimum Thickness : 31 mm
Num. of holes : 5
Solid or Vented : V -
Front Axle
Height : 60.2 mm
Diameter : 334 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 119.9 mm
Brake Disc Thickness : 30 mm
Minimum Thickness : 27.2 mm
Num. of holes : 5
Solid or Vented : V -
Rear Axle
Height : 65.8 mm
Diameter : 315 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 20 mm
Minimum Thickness : 18 mm
Num. of holes : 5
Solid or Vented : V -
Rear Axle, Right
Height : 66 mm
Diameter : 335 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 20 mm
Num. of holes : 5
Solid or Vented : V -
Rear Axle, Left
Height : 66 mm
Diameter : 335 mm
Centering Diameter : 62 mm
Pitch Circle Diameter : 120 mm
Brake Disc Thickness : 22 mm
Minimum Thickness : 20 mm
Num. of holes : 5
Solid or Vented : V
