参考号:2007173C1
Front Axle
Height : 81.5 mm
Diameter : 381 mm
Centering Diameter : 152.4 mm
Pitch Circle Diameter : 184.15 mm
Brake Disc Thickness : 36.5 mm
Minimum Thickness : 33.5 mm
Num. of holes : 10
Solid or Vented : V -
参考号:15661543
Front Axle
Height : 96.7 mm
Diameter : 374.5 mm
Centering Diameter : 152.4 mm
Pitch Circle Diameter : 184.15mm
Brake Disc Thickness : 34.1 mm
Minimum Thickness : 31.1 mm
Num. of holes : 10
Solid or Vented : V -
参考号:2007173C2
Front Axle
Height : 81.3 mm
Diameter : 381 mm
Centering Diameter : 152.4 mm
Pitch Circle Diameter : 184.15 mm
Brake Disc Thickness : 36.5 mm
Minimum Thickness : 33.5 mm
Num. of holes : 6
Solid or Vented : V -
参考号:8U9Z-2C026-A
Front Axle
Height : 113 mm
Diameter : 381 mm
Centering Diameter : 152.4 mm
Pitch Circle Diameter : 184.15 mm
Brake Disc Thickness : 36.5 mm
Minimum Thickness : 33.5 mm
Num. of holes : 10
Solid or Vented : V -
参考号:45251-SFE-J30
Front Axle
Height : 47.2 mm
Diameter : 299.8 mm
Centering Diameter : 64.2 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 26 mm
Number of Holes : 5
Solid or Vented : V
Weight : 7.9 kg -
Front Axle
Height : 47.1 mm
Diameter : 281.8 mm
Centering Diameter : 64.2 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 25 mm
Minimum Thickness : 23 mm
Number of Holes : 5
Solid or Vented : V -
Front Axle
Height : 62.6 mm
Diameter : 282 mm
Centering Diameter : 110 mm
Pitch Circle Diameter : 136 mm
Brake Disc Thickness : 35 mm
Minimum Thickness : 32 mm
Number of Holes : 12
Solid or Vented : V -
参考号:2505097C1
Front Axle
Height : 89 mm
Diameter : 381 mm
Centering Diameter : 137.2 mm
Pitch Circle Diameter : 171.5 mm
Brake Disc Thickness : 36.5 mm
Minimum Thickness : 33.5 mm
Num. of holes : 6
Solid or Vented : V -
Rear Axle
Height : 153.4 mm
Diameter : 299.7 mm
Centering Diameter : 122.7 mm
Pitch Circle Diameter : 184.15 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 25.5 mm
Num. of holes : 10
Solid or Vented : V -
参考号:W8002892
Front Axle
Height : 97.5 mm
Diameter : 306.8 mm
Centering Diameter : 44.2 mm
Pitch Circle Diameter : 82.55 mm
Brake Disc Thickness : 28 mm
Minimum Thickness : 25 mm
Num. of holes : 8
Solid or Vented : V
