Front Axle
Height : 135.3 mm
Diameter : 319.1 mm
Pitch Circle Diameter : 165.1 mm
Brake Disc Thickness : 25.4 mm
Minimum Thickness : 23.9 mm
Num. of holes : 8
Solid or Vented : V -
参考号:411 407 075 A
Front Axle
Height : 92.5 mm
Diameter : 280.7 mm
Pitch Circle Diameter : 130 mm
Brake Disc Thickness : 11.2 mm
Minimum Thickness : 9.4 mm
Num. of holes : 4
Solid or Vented : S -
Front Axle
Height : 135.7 mm
Diameter : 319.1 mm
Centering Diameter : 115.5 mm
Pitch Circle Diameter : 165.1 mm
Brake Disc Thickness : 25.4 mm
Minimum Thickness : 23.9 mm
Num. of holes : 8
Solid or Vented : V -
Rear Axle
Height : 59.4 mm
Diameter : 265.9 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 18 mm
Minimum Thickness : 16.5 mm
Num. of holes : 4
Solid or Vented : V -
参考号:C9AZ 1102 A
Front Axle
Height : 115.1 mm
Diameter : 297.7 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 30.1 mm
Minimum Thickness : 28.4 mm
Num. of holes : 5
Solid or Vented : V -
Rear Axle
Height : 52.6 mm
Diameter : 255.8 mm
Centering Diameter : 58.2 mm
Pitch Circle Diameter : 100 mm
Brake Disc Thickness : 9.9 mm
Minimum Thickness : 8.4 mm
Num. of holes : 5
Solid or Vented : S -
Front Axle
Height : 121.1 mm
Diameter : 274.7 mm
Pitch Circle Diameter : 114.3 mm
Brake Disc Thickness : 22.2 mm
Minimum Thickness : 20.6 mm
Num. of holes : 5
Solid or Vented : V -
Front Axle
Height : 35.8 mm
Diameter : 256 mm
Centering Diameter : 80 mm
Pitch Circle Diameter : 102 mm
Brake Disc Thickness : 20.1 mm
Minimum Thickness : 19 mm
Num. of holes : 4
Solid or Vented : S -
参考号:930.351.048.02
Front Axle, Right
Height : 56.7 mm
Diameter : 304 mm
Centering Diameter : 107 mm
Pitch Circle Diameter : 126 mm
Brake Disc Thickness : 32.0 mm
Minimum Thickness : 30.6 mm
Num. of holes : 5
Solid or Vented : V -
参考号:930.351.047.02
Front Axle, Left
Height : 56.7 mm
Diameter : 304 mm
Centering Diameter : 107 mm
Pitch Circle Diameter : 126 mm
Brake Disc Thickness : 32.0 mm
Minimum Thickness : 30.6 mm
Num. of holes : 5
Solid or Vented : V
